BRAND | Burkert |
Product | p/n: 00178601, Type: 2000 |
Description | 2/2-way angle seat valve, pneu. operated |
Internal code | 4432470 |
Custom code | 84818071 |
Technical specification | 2000-B-2-15,0-EE-RG-GM84-B-C PX51 Type 2000 2000 Control function B opened with spring force Ways/positions 2 2 ways/2 positions Nominal size 15.0 15 mm EE PTFE sealing material RG gunmetal material GM84 G 1/2 socket cable connection Drive version B PA drive, MS threaded socket on the control air connection Drive size C DM 40 mm Special feature PX51 EPS 18 ATEX 2 008 X/IECEx EPS 18,0007 X mech. Ex h IIC T4 Gb/ Ex h IIIC T135°C dB Pressure min 0 bar Pressure max 16 bar Control pressure min 2.50 bar Control pressure max 10 bar Control pressure is 4.30 bar KV 3.70 m3/h Medium temperature min -10 °C Medium temperature max 185 °C Ambient temperature min -10 °C Ambient temperature max 30 °C |
Please Contact Us to Order to offer competitive prices and delivery time for Burkert - p/n: 00178601, Type: 2000 2/2-way angle seat valve, pneu. operated number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
