BRAND | Fristam |
Product | 0545000001 / FZ 20 B |
Description | pump with motor base |
Internal code | 4667556 |
Custom code | 84137045 |
Technical specification | Pump material: 1.4404 (316L) Shaft seal: 404B/1 (2H2P2) FKM bellows carbon/ceramic/NBR Elastomers: NBR with FDA certification Connector type: DIN 11851 Suction side: DN 50 Pressure page: DN 50 Engine: 5.5 kW, n = 1450 rpm 50 Hz, ISO class: F Voltage 400/690V IP55 Funding dates: Product = water Concentration = water/detergent 16 m³/h versus 18 m fls Temperature = up to 100 °C Certificates/exams: - FDA certificate/EG1935/2004 In general: - Alexit No. 91 pure silver finish Engine: - Special motor: engine size 132S - Terminal box location: - with cold conductor temperature sensor - according to efficiency class IE3 Pumphead: - Connections: thread socket DIN 11851 - Suction side left, pressure side right (looking at the pump cover) Shaft seal: - GLRD: simple-looking - left-handed (looking at the pump cover) other agreements: - Terminal box above - Motor with holder feet - Similar to SN 0545580170 but with current GLRD |
Please Contact Us to Order to offer competitive prices and delivery time for Fristam - 0545000001 / FZ 20 B pump with motor base number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
