100M3 /21MBAR - Pietro Fiorentini United Kingdom Sales

BRAND Pietro Fiorentini
Product 100M3 /21MBAR
Description 100m3 /21mbar
Internal code IMP17853
Weight 1

Please Contact Us to Order to offer best price and delivery time fo r Pietro Fiorentini -  100M3 /21MBAR  100m3 /21mbar  number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.WE SELL ONLY ORIGINAL AND NEW PRODUCTSOur company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

More products of Pietro Fiorentini

100M3 /21MBAR

100m3 /21mbar

21-25 FE-25

REGULATOR

250M3 /21MBAR

position of gas expansion

250M3 /300MBAR

position of gas expansion

7013402GD REVAL 182/G ANSI 150 DN 50

Gas pressure regulator with power, self-operated, fail to close, ANSI 150, CE tested according to PED 97/23 / EC module B and EN334, actuator sleeve valve actuator housing GGG40, Ps 16 bar according to EN12186, Pa 6 mbar to 12 bar, Design temperature -20 ° C / + 60 ° C, Operating EN334 -10 (-20) ° C / + 60 ° C, lacquering Actuator housing color: RAL9006, flange galvanized, plastic coated actuator internal Piping I / O 10L, pulse and respiration terminals 12L KG 2335, length 254mm, weight incl. Pilot system 50kg

ANSI150 DN25

Rate (of 2) Screw- Model Steel / Alu

ANSI150 DN50

Rate (of 2) Screw- Model Steel / Alu

APERFLUX 851 ANSI600RF DN 150 7015762

Gas pressure regulator with power, self-operated, fail to open, flanges ANSI600RF, CE approved according to PED 97/23 / EC module B, EN334 and DIN3381, actuator Flat diaphragm, easy to maintain, actuator housing A352 LCB or LCC, depending on the Ps and temperature range, Ps to 100 bar, Pe max 80 bar, higher pressures on request, Pa max 43 (74) bar, design temperature -10 ° C (-20 ° C) / + 60 ° C, Operating EN334 -10 (-20) ° C / + 60 ° C, lacquering Color: RAL9006, flange galvanized, internal Piping I / O 10L, pulse and respiration terminals 12L KG 14598, length 508mm, weight incl. Pilot system 290kg 305 / A + AR100 CS10 (-46 ° C) Pzul to 100 bar, Designtemp. -46 ° C, actuator housing Al (EN AW-6012 anodized), connectors 12L and G ¼ "reactor with int. Fine filter, regulator int. Attenuation and equalization system, Wh 20-60 bar,

AREFLUX 819 ANSI600 DN 150 7009642

Gas pressure regulator with power, self-operated, fail to close, ANSI 600 RF, CE tested to PED 97/23 / EC Module B and EN334, actuator housing ASTM A352 LCB or LCC, Ps to 100 bar depending on the material and temperature range, Actuator sleeve valve Ps 100 bar, Pa max 65 bar, Design temperature -10 ° C / + 60 ° C operating temperature EN334 - 10 (-20) ° C / + 60 ° C, paint color: RAL 9006, galvanized flange, internal piping E / O 10L, pulse and respiration terminals 12L KG 17471, Length 508mm, weight incl. Pilot system 360kg Pilot system 204 / A + R14 / A reflux 7,050,902 Pzul to 100 bar, EO terminals 10L and G ¼ ", with self-adjusting auxiliary pressure stage, with integrated filter, bar, case galvanized guide area 0.7 -43 and painted,

AREFLUX 819 ANSI600 DN 150 7009642

Gas pressure regulator with power, self-operated, fail to close, ANSI 600 RF, CE tested to PED 97/23 / EC Module B and EN334, actuator housing ASTM A352 LCB or LCC, Ps to 100 bar depending on the material and temperature range, Actuator sleeve valve Ps 100 bar, Pa max 65 bar, Design temperature -10 ° C / + 60 ° C operating temperature EN334 - 10 (-20) ° C / + 60 ° C, paint color: RAL 9006, galvanized flange, internal piping E / O 10L, pulse and respiration terminals 12L KG 17471, Length 508mm, weight incl. Pilot system 360kg Pilot system 205 / A + R14 / A SAV-switching device 104M (CE) DN6 "-10" Actuator SAV SB82 (CE) DVGW ANSI300 / 600

DIVAL 507/512 MP

(Compensating diaphragm)

DIVAL 507/512 MP.

(Working diaphragm)

DIVAL160 AP ANSI 600 DN 25 7012133

Gas Pressure Regulator, ANSI 600 RF, spring-loaded, fail to open, CE tested according to PED 97/23 / EC module B, EN334, DIN3381 and EN14382 (2002), flange ANSI 600 RF, Actuator housing ASTM A350M LF2 or ASTM A216M WCB depending Ps and temperature range, Pumax 85 bar, Pd: 0.8 to 4.5 bar, ambient temperature -20 ° C / + 60 ° C, Design temperature -20 ° C / + 60 ° C, pulse, and Respiratory ports 10L (12L) KG 147, overall length 210 mm, Weight 22 kg SAV-switching device SB87 / 103 ANSI300 / 600 7086063 integrated safety shut-off with bypass, connection G ¼ "and 10L (12L) guide portions Who: 1 - 23 bar (at DIVAL160 AP who up to max. 6.8 bar, Whu 0.4 to 5 bar

DIVAL507/G 180BP-10

DN 25 Gas Pressure Regulator, spring-loaded, fail to open, CE approved PED 97/23 / EC module B and EN334, actuator housing EN-GJS400-15, threaded connection G1 "x G1", with integrated SBV port I / O10L (12L) (optional deactivated), with internal pulse line, Pu max 10 bar, Wh: 20 to 110 mbar, Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, 100 mm length without flanges, Pd adjusted to 30 mbar, integrated SBV adjusted to 45 mbar

DIVAL507/G 180MP

Gas-Druckregelgerät DN 25

DIVAL507/G 180TR /DN 25 /X0150730

(Gas pressure regulator, PN20, spring-loaded, fail to open, CE tested according to PED 97/23 / EC and EN334, actuator housing EN-GJS400-15, threaded connection G1 "x G1" (optional Flange), with integrated connecting SBV 12L (optional deactivated - additional charge), with internal pulse line, Pumax 20 bar, outlet pressure range: 300-3000 mbar, Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, 100 mm length)

DIVAL600/G 280MP PN16/25 DN 50 PF7066116G

Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe max 20 bar, Pa 80-350 mbar, design temperature -20 ° C / + 60 ° C, operating EN334 -10 (-20) ° C / + 60 ° C, Paint actuator housing color: RAL9006, Pulse connection 12L, breathing connection G½ "length 254mm SAV-switching device LA / MP 250 + remote display Magnetico (CE) DVGW 7086171PM with remote Magnetico with reed contact, Who guide portions 140-450 mbar, Whu 10-240 mbar, Connection G¼ "or 10L

DIVAL600/G 280TR PN16/25

Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe 20 bar, Pa: 0.28 to 4.2 bar, design temperature -20 ° C / + 60 ° C, operating EN334 -10 (-20) ° C / + 60 ° C, Paint actuator housing color: RAL9006, Pulse connection 12L, breathing connection G½ "

DIVAL600/G 280TR PN16/25 DN 50

Spec. No. 7066008G Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe 20 bar, outlet pressure range: 0.28 to 4.2 bar (For Please order constant adjustment specify, otherwise Machining possible !!!) Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, painting actuator housing hue: RAL9006, pulse terminal 12L, breathing connection G½ " Length 254 mm

Dival 507 mp

regulator

EZR-05X

regulator piloted

FE X1

Two stage pressure regulator for domestic supply, integrated relief valve, over pressure safety shut off valve, under pressure safety shut off valve, Ps 8 bar, Pmax 8 bar, regulation pressure range Pa 13 to 350 mbar, over pressure shut off range Pso 32 to 450 mbar, under pressure shut off range Psu 6 to 200 mbar, relief valve range Ps 10 to 70 mbar, Qn 75 m³/h N.G. at Pe =<0,5 bar, ambient temperatur -20°C / +50°C, design temperatur -20°C / +50°C (other temperatures on request),

FE X1

-20°C / +50°C, Pd: 90 mbar, Pso: 200 mbar

FE25

(Two-stage gas pressure regulator, Ps 8 bar, Pumax: 8 bar, mbar with integrated SBV, output pressure range 13-180 (Via different springs), with integrated safety shut- mbar 300 - with upper cut-off Who 35 gas shortage safety, internal thread connection G 1/2 "x G 3/4 "(other connections on request), Qn 25 m³ / h of natural gas at Pu 0.4 bar, ambient temperature -20 ° C / + 60 ° C, (Low temperature version on request) in line version, connection female thread in body, inlet G- "outlet G1", weight approx 1.4 kg Pds 21 mbar)

FE25S

pump

Flowatch

Multiphase Flow Meter
