BRAND | Güdel |
Product | 10344553 |
Description | transmission |
Internal code | 4800376 |
Custom code | 84834059 |
Technical specification | Transmission unit HPG045_A1_3_ps_900920_73.5_43_l_28_r130_d9_s110_t4_d24_l41to50_f With the following configuration: - Type input drive A - motor flange on one side - Output 1 design - left shrink disc - Gear ratio 3.00 - Accuracy class PS - standard torsion game - Shaft sprocket 900920 Shaft sprocket WR20 p=5/z=20 Straight toothed - Glygoyle 460 oil selection - Shrink disc 404531 Shrink disk for AE045 transmission - Coupling 404524 Coupling 045 k Type2 Ø24H7 - Length L6 73.5 mm - Centring flange 0206816 Centring flange HPG045 L43 - Assembly output component left - Height of spacers 28.00 mm - Motor flange 0106087 Motor flange 045 25x125x125 ø130/110 - Transmission flange 0212823 Transmission flange HPG 045 ø65/34x40.5 Length 2 - Engine oil pass-through drill. (8) 0,0 mm - Length of interference contour input 186.00 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Güdel - 10344553 transmission number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
