12102072/010 - RTK United Kingdom Sales

BRAND	RTK
Product	12102072/010
Description	Motor control valve
Internal code	4639774
Custom code	84818059
Technical specification	Motor control valve - series MV 5211 straight through Nominal size DN 50, nominal pressure PN 16 housing material cast iron EN-GJL-250 flanges with sealing surface according to DIN Spindle seal: PTFE/carbon roof sleeves Characteristic line/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 24 m³/h, stroke 30 mm seat diameter 32 mm surface treatment with zinc dust primer CE marking according to Pressure Equipment Directive (PED) Electric Actuator - type ReAct 30E-028 Actuating force 3 kN, including manual adjustment AC motor 115 V 50/60 Hz positioning speed 0.28 mm/s, stroke 30 mm Protection class IP 65 with pillars - additional limit switches (2 pieces)

Please Contact Us to Order to offer competitive prices and delivery time for RTK - 12102072/010 Motor control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
