| BRAND | Interroll |
| Product | MI-DMI AC165I-S++0+A3EGDHD-450mm |
| Description | Trommelmotor |
| Internal code | 1112265 |
| Technical specification | Schutzgrad IP 66 SL Rohrlänge 450,0 mm Stirnflächenweite zw. Deckeln 467,0 mm EL/LW/BF Einbaulänge 490,0 mm AGL Achs-Gesamtlänge 550,0 mm Leistung 750 W Wicklung Polzahl 4 Drehmoment [Nm] 99,7 Bandzugkraft 1.215 N Getriebeübersetzung 19,64 Geschwindigkeit bei Frequenz 1 0,593 m/s Frequenz 1 50 Hz Wicklung Phasenzahl 3 hohe Spannung 400 V niedrige Spannung 0 V Geschwindigkeit bei Frequenz 2 0,711 m/s Frequenz 2 60 Hz hohe Spannung 2 480 V niedrige Spannung 2 0 V größter Außendurchmesser 164,0 mm Rohrform Sonderzylindrisch Rohrmaterial Stahl: St37-2 / AISI 1015 Deckel Ausführung Standard Deckel Material ALU AlSi10Mg(Fe) / AL239 Abdichtmaterial / Labyrinth Stahl Welle Ausführung Spezialschaft mit 1 SW Welle Material Stahl: 11SMnPb30 / AISI Welle Durchmesser 40,0 mm Welle Schlüsselflächenweite 30,0 mm Welle Schlüsselflächenlänge 30,0 mm Motor Option Bremse Bremsspannung 24 V Öl-Type Mineralöl Viskosität 150 Elektrische Anschlussseite B-Seite Elek. Anschluss Typ Winkelverschraubung Elek. Anschluss Material Polybutylen Terephthalat Leistungskabellänge 5,0 m Leistungskabeltyp ungeschirmt; nicht halogenfrei |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DMI AC165I-S++0+A3EGDHD-450mm Trommelmotor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
