BRAND | LAIPPLE KEB |
Product | 19F5CDH-350F |
Description | controlled frequency converter |
Internal code | 4441217 |
Custom code | 85044088 |
Technical specification | KEB Combivert F5-COMPACT equipment: integrated filter - leakage current 16 mA brake transistor GTR7 heatsinktup air cooler specifications power 42 kVA Motor 30 kW 2/4P 50/60 Hz Input voltage range 305... 528 AC 3 PH output voltage 0... Uin Rated output current 60A max. output frequency 599 Hz Switching frequency 4kHz protection class IP20 Dimensions (WxHxD) 297 x 340 x 255 mm |
Please Contact Us to Order to offer competitive prices and delivery time for LAIPPLE KEB - 19F5CDH-350F controlled frequency converter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
03292626/0476815, 07.F4.S1D-3420/1.2 (OBSOLETE)
frequency converter
rectifier half wave period
Version: 1.0 Input: 50/60 Hz 3AC 380 volt (38 o volt?) Output: 0-1600Hz Power: 1.0 KVA
KEB COMBIBOX
BRAKE M2N 7Nm BRAKE P2O 12W CLUTCH M2N 7Nm CLUTCH P2O 15W VOLTAGE 24V A WAVE LENGTH: 14; 30 Shaft LENGTH: 11; 23 Flange: 140 B5 TERMINAL BOX: B2
It has offered an alternative product. There are a limited number.
static frequency converter KEB COMBIVERT F5-BASIC Article no. 07.F5.B1B-3B0A Rated Power 1.8 kVA Rated voltage 3 x 305 ... 500 V AC ± 0% or 420 ... 720 V DC ± 0% Rated output current 2.6 A Max. motor Power (2- / 4-pole motor) 0.75 kW Output voltage 3 x 0 ... UGRID Output frequency 0 ... 408 Hz Nominal switching frequency kHz 2/4/8/16 Endurance sec 4.7 A for 30 seconds. Protection IP 20 Dimensions W x H x T: 90 x 220 x 160 mm
controlled frequency converter
KEB COMBIBOX Brake M2N (Nm): 30 P2O brake (W): 21 Coupling M2N (Nm): 30 Coupling P2O (W): 28 Voltage (V): 24 A wave ᴓ, length: 19,40 Welle From ᴓ, length: 19,40 Terminal box position: B2
KEB COMBIBOX Brake M2N (Nm): 30 P2O brake (W): 21 Coupling M2N (Nm): 30 Coupling P2O (W): 28 Voltage (V): 24 A wave ᴓ, length: 24,50 Welle From ᴓ, length: 24,50 Terminal box position: B2
conbivert F4
controlled frequency converter
KEB COMBIBOX Coupling M2N (Nm): 65 Coupling P2O (W): 35 Voltage (V): 24 A bore ø: 38 G7 A flange ø 200 B5 Welle From ø, length: 28,60 Terminal box position: B2 Terminal box IP65, 2 x threaded M16x1,5 On the output side oeldicht Commodity code: 85052000 Total Net Weight: 49.005 KG
combibox
Input shaft ø, length: 24,50 Output shaft ø, length: 24,50 Output flange ø : 200 B5
(KEB COMBIVERT F5-BASIC controlled inverter Furnishing: Braking transistor: GTR7 Heatsink type: intercooler mounted version Technical specifications: Power: 2.8kVA Motor: 1.5kW 2 / 4P 50 / 60Hz Input voltage range: 400 VAC 3 PH Output voltage: 0 ... Uin Rated output current: 4.1A Max. Short time current limit: 7,4A Max. Output frequency: 400 Hz Switching frequency: 8kHz Protection: IP20 Dimensions (W): 90 x 220 x 160 mm Commodity code: 85044084 Single Net Weight: 1.900 KG)
KEB COMBIVERT F5-BASIC controlled frequency converter
