| BRAND | Pietro Fiorentini |
| Product | FM7064001G + FM7086500P |
| Description | Gas pressure regulator + SAV switching device |
| Internal code | 4873983 |
| Custom code | 84811019 |
| Technical specification | DIVAL500/G BP (FM7064001G) - Gas pressure regulator - 1 piece DN 25, PN10, spring-loaded, fail to open, CE approved according to DGR 2014/68/EU and EN334, EN GJS actuator housing 400-18 [EN 1563), thread connection G1" x G1", with integrated SBV connection G1/4" or 12L (can be deactivated as an option - subject to an additional charge), with internal pulse line, Pu max 10 bar, Outlet pressure range: 20-110 mbar, design temperature -20°C/ +60°C, operating temperature EN334 -10 (-20) °C/+60°C, overall length 100 mm overall length without flanges 100 mm SAV switching device LA/BP 507 (CE) DN 25 (FM7086500P) - 1 piece integrated safety shut-off valve (SAV), with bypass and internal impulse hole, Wdso 30-180 mbar guide ranges, Wdsu 10-60 mbar, ventilation connection G1/8" or 10L, optional Impulse connection G1/4" (closed with blind plug) |
Please Contact Us to Order to offer competitive prices and delivery time for Pietro Fiorentini - FM7064001G + FM7086500P Gas pressure regulator + SAV switching device number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
valve seat seal
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
membrane
guide ring
guide ring
O-Ring
butterfly valve
GAS REGULATOR
DIVAL600/G 280TR PN16/25 DN 50
Spec. No. 7066008G Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe 20 bar, outlet pressure range: 0.28 to 4.2 bar (For Please order constant adjustment specify, otherwise Machining possible !!!) Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, painting actuator housing hue: RAL9006, pulse terminal 12L, breathing connection G½ " Length 254 mm
Pilot-action pressure reducer/regulator
O-Ring
O-Ring
