202150700021 - Pietro Fiorentini United Kingdom Sales

BRAND	Pietro Fiorentini
Product	202150700021
Internal code	4858024
Technical specification	REVAL 182/A ANSI 150 DN 200 7013942 Gas pressure regulator with auxiliary energy, self-medium controlled, fail to close, ANSI150, CE approved according to DGR 97/23/EC module B and EN334, pipe slider actuator, A216M WCB actuator housing, Ps 16 bar in accordance with EN12186, Pd: 7 mbar to 12 bar, Design temperature -20°C/+60°C, operating temperature EN334 - 20°C/+60°C, 10L internal piping, pulse and Breathing connections G 1/4" or 12L KG 27282, overall length 543 mm, weight including 300kg pilot system Same as factory number: 202150700021 consists of: 1. 204/A x Reval (Germany) PFP201500379 Pilot controller for REVAL, Pzul up to 25 bar, connection G¼” or cutting ring fitting 12L, Wh 0.3 -12bar Same as factory number: 202150700032 Pds:? Bar spring 4.0-12.0 bar 2nd SAV SB82 BP (CE) DVGW ANSI 150 DN 200 7076752 actuator valve plate element with integrated bypass, valve rod with Pre-pressure compensation Weight incl. 70kg switching device Same as factory number: 202150700024 3rd SAV control unit 103M (Germany) DN6"-10" PFP201400687 with manual release and membrane rupture protection, with upper and lower shutdown, management areas Who 1.8 - 23 bar, Whu 0.15 - 8.0 bar, connection G1/4" or cutting ring screw connection 12L Same as factory number: 202150700026 PDSO:? Bar spring: 2.8-8.0 bar Pdsu: 0.15 bar spring 0.150-0.650 bar

Please Contact Us to Order to offer competitive prices and delivery time for Pietro Fiorentini - 202150700021 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
