20F -90LP/4 TF - Nord United Kingdom Sales

BRAND	Nord
Product	20F -90LP/4 TF
Description	spur gear motor
Internal code	4815735
Technical specification	Product name Spur gear motor Engine speed 1.415 rpm Translation 3.15 Output speed 449,000 rpm Operating factor 2.40 Output torque M2 (Nm) 31.90 Power (kW) 1,500 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Rated current 1 (AMP) 5.59 Rated current 2 (AMP) 3.23 Cosine 1 0.79 M4 transmission design Housing type flange B5 Wave size 25X60 Flange diameter (mm) 250 Venting Pressure venting Thermal motor protection cold conductor, 3x155°C Star circuit type Terminal box layer/ cable connector 1/I

Please Contact Us to Order to offer competitive prices and delivery time for Nord - 20F -90LP/4 TF spur gear motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
