| BRAND | Demag |
| Product | DRF 200 ZBF 63 A 8/2 B003 |
| Internal code | 5012202 |
| Weight | 25 |
| Technical specification | The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Design key DRF200--1/84,6 - ZBF 63 A 8/2-B003 Output speed 9.8/39.5 rpm Motor speed 825/3345 rpm Output 0.070/0.300 kW Operating time 40/40% Motor protection class IP 54 Ambient temperature gearmotor -10... +40 °C Installation height ≤ 1,000 m Translation 84.60 Terminal box position on the right,, 1 Electrical data: Line voltage Y 440 V Frequency 60 Hz Current Y 0.73/1.05 A Brake technical data: Braking torque 1.4 Nm Voltage 198 V DC Current 0.10 A with brake rectifier GF 440 V AC equipment: Insulation in accordance with thermal class F Light fan disc Oiltight bearing plate Travel speed V= 6.0/24.0 m/min Friction wheel width 73 mm GF brake rectifier abnormal brake tension Friction wheel Thelan - Standard Execution in accordance with order number: 368884 from 2016 coloring: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive |
Discover the superior quality and performance of the Demag DRF 200 ZBF 63 A 8/2 B003 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DRF 200 ZBF 63 A 8/2 B003 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DRF 200 ZBF 63 A 8/2 B003 :
At RADWARD LTD , we offer the DRF 200 ZBF 63 A 8/2 B003 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the DRF 200 ZBF 63 A 8/2 B003 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DRF 200 ZBF 63 A 8/2 B003 by Demag in United Kingdom?
You can purchase DRF 200 ZBF 63 A 8/2 B003 by Demag from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the DRF 200 ZBF 63 A 8/2 B003?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Demag in United Kingdom?
While we are not the official distributor or seller of Demag in United Kingdom, we source our products from reliable channels and offer you original Demag equipment at competitive prices.
How can I access DRF 200 ZBF 63 A 8/2 B003 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DRF 200 ZBF 63 A 8/2 B003 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DRF 200 ZBF 63 A 8/2 B003?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
