828.500 Type 53 2 U 25 TEFC - Combimac United Kingdom Sales

BRAND	Combimac
Product	828.500 Type 53 2 U 25 TEFC
Internal code	4228222
Technical specification	Technical details Article nr. 828.500 Type 53 2 units 25 TEFC Design / Description = low magnetic - cast design NSN = 6105-17-051-8891 = aluminum cast Method of cooling (IEC 60034-6) = IC4A1A1 Medium air Execution (IEC 60034-7) IM B35 Supply voltage (IEC 60092) = 440V 3ph 60 Hz Frame size (IEC 60072-1) 160 M Power rating (IEC 60034-1) = 7.5 kW Special Duty cycle (IEC60034-1) = S1 Connection T-Box-Right-SoS Connection / DoR (IEC 60034-8) = Delta Diagram D.317.311 / A-086 Method of starting IEC 60034-12 = DOL - - Number of poles = 6 Rotation CW-SoS IEC 60034-8 Speed (synchr.) Single = 1200 rpm Insulation F Rise - Ingress Protection (IEC 60034-5) = IP55 Ambient Min. 0 ° C Max. +50 ° C Thermal protection (IEC 60034-11) = Thermistors - - PT100 not applicable Heater (s) = - - Encoder - I / O - Cable tassels (threaded holes) = Main - Aux. - Shock Grade / Specification = 30g all directions Loading time - Material (frame) = aluminum - EN AC-AlSi10Mg - EN1706 - 3.2381.01 Balancing planes Balancing (ISO 21940-32) = full key Level MIL-STD-167-1A, type II not applicable Shaft / flange standard size = EN 50347 Shaft material Shaft loads not applicable = Shaft end one Classification / Directive = - - Paint system = Light Gray KN103, CN P212E Efficiency (not applicable) - Dimensions / Drawing = 7324A2 for information only Mass (approx.) 90 kg

Please Contact Us to Order to offer competitive prices and delivery time for Combimac - 828.500 Type 53 2 U 25 TEFC number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
