BRAND | Bd Sensors |
Product | 780-1003-E-1-3-N11-100-1-070 |
Description | pressure switch |
Internal code | 4446590 |
Custom code | 90262020 |
Technical specification | DS 200 Code input: 0... 100 bar Electrical output: 4... 20 mA/2-wire Ex version 1: II 2G Ex ia IIC T4 Gb ATEX: ibexu06ATEX1050 X Pi: 660mW ui: 28 V Ii: 93 mA CI: #0 nF Li: approx. 0 μH nameplate: BDS GmbH supply: 15... 28 VDC switching output: 1 switching output Accuracy: 0.35% FSO IEC Electrical connection: M12x1 plug (5-pin) metal Supply +: 1 Supply -: 3 Shield: via pressure connection switching output 1:4 Type of protection: IP65 Labeling Display: Standard Unit: bar Mechanical connection: G1/2" DIN 3852 Seal: FKM special design: with choke screw M4 Nameplate - position: standard |
Please Contact Us to Order to offer competitive prices and delivery time for Bd Sensors - 780-1003-E-1-3-N11-100-1-070 pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
