BRAND | Ephy Mess |
Product | 903270704000001 |
Description | Tempetature probe |
Internal code | 4858456 |
Custom code | 90259000 |
Technical specification | PR-SPA-EX-WKF iBEXu 14 ATEX 1281 U, II 2G Ex eb IIC Gb Single cold wire, EPTC-DSH-SGH, 1xbarium titanate NAT: 100°C, R<100Ω, ±5K in accordance with DIN VDE V 0898-1-401 stainless steel, screw housing, casting, Step sleeve or socket: ø6x15mm Total length: 30.5mm VSB: fixed, stainless steel, M6x7.5mm/SW 10x8mm Supply line: 1x [2xAWG 26/7-Cu-silvered/PTFE/glass fibre/PTFE, diameter: 3.2 mm], KL=1000 mm, WH (WH/RD), Measurement range: -45°C... +180°C Ambient temperature: -45°C... +180°C Dielectric strength: 3.0 kV AC. 50 Hz/ 1min |
Please Contact Us to Order to offer competitive prices and delivery time for Ephy Mess - 903270704000001 Tempetature probe number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
