DDS-MR984.5.4.3.K.1 - Beck United Kingdom Sales

BRAND	Beck
Product	DDS-MR984.5.4.3.K.1
Description	differential pressure transmitter
Internal code	1859869
Weight	0.13
Custom code	90262080
Technical specification	Pa/0.. 1000 Pa. With display For air and non-aggressive gases. Linear output: 0-10V or 4-20mA selectable Output signal can be switched to radical. Measuring range 1:0-500 Pa, measuring range 2:0-1000 Pa. perm. Overpressure: 20 kPa, burst pressure: 40 kPa. Additional switching output npn. Dimensions: diameter 85 x 58 mm (DxH), protection class IP 54. 4 notch bolt fixing Delivery including climate set straight type 6555 consisting of: 2 duct connection nipples type 6551 and 2 m PVC hose 6 mm diameter. Power supply: 18-30 V AC/DC Previous type designation: DDS-MR984.3.3.3.1.D Datasheet no. 1325

Please Contact Us to Order to offer competitive prices and delivery time for Beck - DDS-MR984.5.4.3.K.1 differential pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

DB.pdf
