Buy ASF2-20RD-241708R from Steimel in United Kingdom

BRAND

Steimel

Product

ASF2-20RD-241708R

Internal code

5153724

Weight

Technical specification

A-SF2/20RD-VLFM, pump unit according to ATEX

1.5kW, 1500, 400/690V, IE3, 50Hz, IP65, PTC, F, VIK

gear pump unit	:	SF 2/20 RD - VLFM
in accordance with Directive 2014/34/EU (ATEX)
Item no. Dimension sheet Spare parts list Suction and pressure connection housing parts Sprocket shafts, noise-opti. warehousing	: : : : : :	ASF2-20RD-241708R DPA052D-241686R DET052020-182207R G 1/SAE 1 EN-GJL-250 (GG-25) 16MnCrS5, egh., oblique	:
Multi-layer MD
shaft sealing	:	radial shaft seal
elastomers Temperature monitoring	: :	FKM PT100 resistance thermometer, wired in the terminal box, BTW004 Type examination certificate: ibexu14ATEX1281 U
Limit value switch pumping medium viscosity temperature flow rate	:	On site, limit value max. 90°C
:	lube
:	50-5000 cSt
: :	10 - max. 80°C approx. 28.5 l/min

printing	:	5 bar
rpm	:	1450 rpm
pressure relief valve opening pressure adjustment range	: :	8 bar 2-20 bar
direction of rotation	:	right
coupling pump carrier with foot three-phase motor power rpm Voltage/ frequency Protection class insulation class Ignition protection type motor protection Ambient temperature construction version Aggregate paint ATEX type plate ATEX label pumping unit	:	BKUA040-1424-303 (ATEX)
: : : : : : : : : : : : : :	BLF052200110LA21 LDX090-04-064 (HEW) 1.5 kW 1500 rpm 400/690 volts/50 Hz IP 65 F to B II 2G Exdb eb IIC T4Gb 3 cold conductors -20°C to +40ºC B5 VIK primed RAL 6011 (HDO058) ETY924FLEND-PE03
:	II 2G Ex h IIB T4Gb X

Please note the regulations
in accordance with Directive 2014/34/EU (ATEX)
regarding the use of our pumps in
potentially explosive areas.
Prerequisite for operation in:
Zone 1 or 2
Temperature class T4
Ambient temperature -20°C to +40°C
Explosion group IIB (gas)
Temperature monitoring at the pump using
Resistance thermometer: Pt 100 included
Limit value switches and cabling: on site!
(limit value max. 90°C)
Before starting up the pump, the temperature monitoring must
Be functionally connected on site!

Discover the superior quality and performance of the Steimel ASF2-20RD-241708R with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The ASF2-20RD-241708R is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of ASF2-20RD-241708R :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the ASF2-20RD-241708R at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the ASF2-20RD-241708R ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Steimel products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
