B014782 - EUROTECH United Kingdom Sales

BRAND	EUROTECH
Product	B014782
Description	Side channel blowers
Internal code	4283576
Custom code	84148019
Technical specification	Side channel compressor^2, type DG-630 (330 m3/h; 4.0 kW; 50 Hz, DS 3~) IE3 Side channel compressor^2, type DG-630 (330 m3/h; 4.0 kW; 50 Hz, DS 3~), IE3 This single-stage version of the side channel compressor is called complete with IE3 motor, electrical terminal box, single and Exhaust silencer supplied. Technical data at 50/60 Hz applies: Suction capacity: 320/390 m3/h Ultimate vacuum (short-term) ፦270/ -315 mbar ultimate vacuum (operating range) ፦220/ -250 mbar Pressure: 320/320 mbar Power: 4,0/4,6 kW Voltage: 220-240/ 345-415 V Current: 14.3/8.2 A 50 Hz Voltage: 220-275/380-480 V Current: 16.2/9.3 A 60 Hz Sound level: 75/79 (dB) A Energy efficiency: IE3 Degree of protection: IP 55 Connection thread: 2" Also mounted: 1x pipe piece 2" x 200 mm, 1x T-piece with 3 x 2" Female thread including suction limitation valve with Vacuum gauges. Drawing Number: BSKV-DG.0630.26.015.IE3

Please Contact Us to Order to offer competitive prices and delivery time for EUROTECH - B014782 Side channel blowers number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
