BRAND | Cedaspe |
Product | BU36F800P47 |
Internal code | 4224343 |
Technical specification | BUSHING,TRANSFORMER HV,295 MM DIA X 1 M BUSHING: PARENT EQUIPMENT/FUNCTION: TRANSFORMER HV; SIZE: 295 MM DIA X 1 M AND 517 MM LG; MATERIAL: PORCELAIN; ELECTRICAL RATING: 8000 A, 36 KV; STANDARD/SPECIFICATION: EN50243; ADDITIONAL DATA: ITEM ADDITIONAL DESCRIPTION: 95 KV PF RATING, 250 KV BIL RATING, 550 MM ARCIN G DISTANCE, 1560 MM CREEPAGE DISTANCE, BOTTOM CONNECTOR, CT 300; SYSTEM PAREN T EQUIPMENT INFORMATION: FOR 70 MVA AU XILIARYATRANSFORMER, KKS # 01 02 03 04B BT02GT001 OF MITSUBISHI STEAM GENERATIN G SET MODEL # TC-4F-40 AT JEDDAH SOUTH STEAM POWER PLANT. CEDASPE: Model#36-8-P47 CEDASPE: P/N#BU36F800P47 CEDASPE: IS.36/8000-P4-1560VITTP120CT300 CEDASPE: DWG#P3327/4 HYUNDAI (HHI) (FM): 10BBT-E06-V001-001 POSITION 1 |
Please Contact Us to Order to offer competitive prices and delivery time for Cedaspe - BU36F800P47 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
