BRAND | HIMMEL |
Product | CAZ122-A |
Description | worm gears |
Internal code | 4740636 |
Technical specification | Article number 2230057699 Dimension sheet: CAZ04A Transmission design/Type: HIMMEL® -Solo-worm gear/ HEAVEN® -Solo-Worm Gear Transmission type/ Type: CAZ122-A Dimension picture/ Dimension sheet: CAZ04A Translation/Ratio [i]: 174.10 Color/colour: RAL 7011 Iron grey 2K/Iron grey 2K-PUR Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP54 Design/mounting position: H-01-A Output torque [Nm]: 3850.0 Direction of rotation: left/left [CCW] Output shaft transmission/Output shaft [mm; inch]: H90x300 Gearbox bearing: associated bearing/assigned bearings Oil type/Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 8.50 Flange diameter/flange diameter [mm; inch]: 377 Shaft material/Shaft material: GG Transmission sealing/Sealing: shaft seal (WDR)/shaft seal ring Drive shaft AV unit/Input shaft [mm; inch]: V38x80 |
Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - CAZ122-A worm gears number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
