| BRAND | CD AUTOMATION |
| Product | CD3S10090480SSR |
| Description | Series S Thyristor Controller |
| Internal code | 503116 |
| Weight | 1 |
| Custom code | 85365003 |
| Technical specification | Type: CD3000S-1PH/90A/240/480V/NO/SSR/ZC/NF G.No. - Circuit: Single-phase controller - Load current: 90 A (90A @40 °C; 72A @50 °C) - Load Voltage:240V (480 V max) - Control: Logic (OFF < 1.0 Vdc, ON 5... 30 Vdc) Current: typ. 12 mA - Dimensions: 117 x 120 x 159 mm (WxHxD) - ideal for heating control with resistive load (zero crossing) - Anti-parallel switched thyristor controller - CE mark - Space-saving due to integr. heatsink - RC link and varistor integrated - LED status indicator - DIN rail mounting or screw mounting Option (surcharge) - Control: 4... 20mA (signal powered; 6.5 Vdc min.) - Control: Logic (OFF = 1.0 Vdc, ON = 5... 30 Vdc) Current: typ. 5mA - Partial load error: * Partial load fault detection from 50msec. turn-on time * Partial load fault detection from 80% of the Nominal flow * automatic measurement of the nominal current by means of a button at 100% control variable for approx. 1 min. - AC input: 110-240Vac, ± 15% 20mA - UL label - Momentary switching for phase control |
Please Contact Us to Order to offer competitive prices and delivery time for CD AUTOMATION - CD3S10090480SSR Series S Thyristor Controller number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
