CDH582M-00002 - TR Electronic United Kingdom Sales

BRAND	TR Electronic
Product	CDH582M-00002
Description	Absolute encoder
Internal code	4914321
Custom code	90318020
Technical specification	CDH582M*8192/65536 EPN NTS 12H7 + FS2 EN 61508 EN 61800-5-2 EN 62061/EN ISO 13849 IEC 61800-5-3 SAFETY CDH582MD+FS02 EPN Sil2/PLD STEP COUNT 8,192,000 REVOLUTIONS 65,536,000 HOLLOW SHAFT VARIANT FLANGE TYPE GROOVE FOR PIN D4 SHAFT DESIGN 12H7 HOLLOW SHAFT SUPPLY VOLTAGE 10-30VDC POWER LOSS < 3W PROTECTION CLASS IP54 WORKING TEMPERATURE -40+85°C OPTION ENC CONFORMANCE CLASS C FLANGE RING PIN/GROOVE IEC 61158/IEC 61784-1 Legacy profile PN Spec. 2.3 PNO PROFILE PRESET ON-THE-FLY PROFIsafe profile V2.4 PROFISAFE Profile V2.6.1 SAFE ABSOLUTE POSITION (SAP) SAFE SPEED (SSV) TR profile PROFINET/PROFISAFE INTERFACE CONNECTION TYPE 1X4P.M12 PLUG (A-COD) 2X4P.M12 SOCKET (D-COD) RADIAL CONNECTION DIRECTION PIN ASSIGNMENT NUMBER TR-ECE-TI-DGB-0323 DRAWING NO. 04-CDH582M-M0002 VERSION NO. 000 MATCHING PLUG NO DOCUMENTATION NUMBER DOCUMENTS AL: N ECCN: N UL APPROVALS USA+CANADA

Please Contact Us to Order to offer competitive prices and delivery time for TR Electronic - CDH582M-00002 Absolute encoder number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
