BRAND | HIMMEL |
Product | CF10-G56S4 |
Description | worm gear motor |
Internal code | 4729821 |
Custom code | 85015100 |
Technical specification | Dimension sheet: CF14/1369 Transmission design/Type: HIMMEL® worm gear motor/HIMMEL® -worm Gear Transmission type/Type: CF10-G56S4 Dimension picture/Dimension sheet: CF14/1369 Output speed [1/min; 1/rpm]: 4.00//4.80 Translation/Ratio [i]: 348.23 Color/colour: RAL 7016 anthracite grey 2K/Anthracite grey 2K-PUR Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP54 Model/mounting position: B5-01-B Output torque [Nm]: 41.9//34.9 Direction of rotation: left/left [CCW] Output shaft transmission/Output shaft [mm; inch]: V18x40 Gearbox bearing: associated bearing/assigned bearings Oil type/Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.22 Flange diameter/flange diameter [mm; inch]: A105 Shaft material/Shaft material: C45 Transmission sealing/Sealing: shaft seal (WDR)/shaft seal ring Electrical version/Electrical design: CE Number of poles/Poles: 4 Nominal frequency/ Nominal frequency [Hz]: 50//60 Nominal voltage/Nominal voltage [V]: 220-240/380-420//220-240/440-460 Circuit/Wiring: S100//S100 (D/Y//D/Y) Rated power/ Nominal power [kW]: 0.06//0.06 Name motor speed/ Motor speed name [1/rpm]: 1380//1660 Current/Nominal current In [A]: 0.42/0.24//0.42/0.24 cosPHI/cosPHI: 0.68/0.70 KK location/Terminal box position: 1C KK version/Terminal box type: plastic/plastic Winding protection/Motor protector: without/without Output shaft Motor/ Output shaft [mm; inch]: V11x24.5 Engine sealing/Sealing motor: normal/normal Insulation class/Insulation class: F Operating mode/Duty type: S1 Fan/Fan: plastic/plastic |
Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - CF10-G56S4 worm gear motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
