BRAND	Ascell Sensor
Product	CFSI 100 KG IP68
Description	Loadcell
Internal code	1782404
Weight	0.8
Technical specification	Ref. 104101 Divisions nLC 3000 Minimum Dead load Emin 0 kg Z= Emax / 2DR 3000 Y= E max./ Vmin. 10000 Rated Capacity Emax 50 - 75 - 100 - 150 - 300 - 500 kg Rated Sensitivity C 2 ± 0,1 % mV/V Rated Input Voltage 10 V dc Input Voltage Range 5...15 V ac/dc Input Resistance RLC 350 ± 3 Ω Output Resistance 350 ± 3 Ω Zero Balance ± 2 % Emax Insulation Resistance at 50 V DC > 5000 MΩ Service Overload > 150 % Emax Overload Limit > 300 % Emax Temperature Range : Compensated - 10 ... 40 ºC Operating - 30 ... 85 ºC Storage - 30 ... 90 ºC Max. Nonlinearity 0,02 % Emax Max. Hysteresis 0,02 % Emax Max. No repeatability 0,01 % Emax M Max. Creep in 4 hours 0,03 % Emax Max. Zero Recovery Test in ½ hour 0,011 % Emax Max Temperature effect : On Sensitivity 0,0013 % Emax / ºC On Zero 0,0014 % Emax / ºC Weight 800 g Cable Length 5 m Environmental Protection IP68 - DIN 40050 (100h 1m)

Please Contact Us to Order to offer competitive prices and delivery time for Ascell Sensor - CFSI 100 KG IP68 Loadcell number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
