BRAND | Micro-Epsilon (Eltrotec) |
Product | 480055 |
Description | thermoMETER CS Miniature infrared sensors for OEM applications |
Internal code | 4719457 |
Custom code | 9025 19 00 |
Technical specification | CS-SF15-C1 miniature pyrometer (hardware version 3) Temperature measuring range: -40° - 400°C (can be expanded via software to 1030°C) Optical solution: 15:1 Focus: 0,8mm @ 10mm (optional with CF-lense) Spectral range: 8 - 14µm Temperature solution: 0,1 °C Response time: 25 ms – 999s (adjustable via software/ optional) Temperature resolution: 0,1 K System accuracy: ±1,5 % or ±1,5 °C (whichever is greater) Repeatability: ±0,75 % or ±0,75 °C (whichever is greater) Temperaturcoefficient: ±0,05 K/K or ±0,05 %/K Ambient temperature: -20°C - 80°C Storage temperature: -20°C - 85°C Power supply: 5-30 VDC; 4 mA (without LED); 10 mA (with LED) Outputs: analogue: 0-5 V, 0-10 V alternative: alarm Inputs: programmable functional input for external emissivity setting (0-5 VDC), Hold function, ambient temperature compensation (via USB programming interface/ optional) Emissivity: 0,95 (preset) Transmissivity: 0,100 - 1,100 adjustable via software Signal processing: peak hold, valley hold, average, extended hold function with threshold and hysteresis Environmental rating: IP63 Scope of supply: Sensor incl. mounting nut, 1 m sensor cable, manual. |
Please Contact Us to Order to offer competitive prices and delivery time for Micro-Epsilon (Eltrotec) - 480055 thermoMETER CS Miniature infrared sensors for OEM applications number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
