BRAND | Technotrans |
Product | cs 180t9.1 |
Internal code | 4838162 |
Custom code | 8419 89 98 |
Technical specification | Key features: - logotherm - gesture-enabled 7" multi-touch display in modern HMI design - LongLife stainless steel cartridge heater - Long-term warranty on “longlife” heating - Durable magnetically coupled peripheral stainless steel pump - Tankless device for minimal oxygen uptake Operating fluid, water heat transfer medium Flow temperature max. 180 °C Required water quality https://www.technotrans.de/produkte/filtrieren-und-separieren/wasserqualitaet Continuous heating via solid state semiconductor relays Heating capacity 9 kW Indirect cooling, WT 7/02 Cooling regulation solenoid valve Cooling capacity 40 kW at circulating medium temperature 130 °C at a cooling water temperature of 15 °C WP 60 MK operating pump Delivery volume max. 60 l/min Delivery pressure max. 6.0 bar Scheme CompactControl gesture-enabled 7" multi-touch display ports Operating voltage 400V/50Hz/3Ph+Pe 3.0 m supply line with CEE plug 16 A Circulating medium connections forward/return G 1/2" Cooling water connections flow/return G 1/4” Cooling water pressure 3-4 bar Control cabinet protection class IP 54 Dimensions (LxWxH) 674x356x607 mm Side panels RAL 260 40 45 LED blue Case/front panel RAL 7012 basalt grey Ambient temperature max. 40 °C Volume DIN 45635T1, LpA 1m <70 dB (A) Service: - logotherm - gesture-enabled 7" multi-touch display in modern HMI design Heating: - “longlife” stainless steel heating cartridge - Long-term warranty on “longlife” heating Pumping technology: - Durable magnetically coupled peripheral stainless steel pump Measurement technology/ Alerting: - Electronic temperature measurement in advance - Electronic temperature measurement in return - Electronic flow measurement (low maintenance) - Audible and visual alarm Other equipment features: - “Tankless” device for minimal oxygen uptake - Medium-contact components made of corrosion-resistant materials - Cooling via solenoid valve - Good accessibility for maintenance work through removable cladding sheets - Interface port on the front of the device - Optimized placeability due to compact design - IP 54 control cabinet - Strainer in the coolant flow The following options are added to the standard equipment: (Options may replace standard equipment) - Profibus interface - Small version wheels - Operating language (touchscreen): German |
Please Contact Us to Order to offer competitive prices and delivery time for Technotrans - cs 180t9.1 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
