| BRAND | Micro-Epsilon (Eltrotec) |
| Product | CSmi-SF15-C6/3 |
| Internal code | 4819163 |
| Technical specification | 4800523.063 Temperature range: -40 to 1030 °C Optical resolution: 15:1 Focus: 0,8 mm @ 10 mm (optional with CF-lense) Spectral range: 8 – 14 μm Response time: 14 ms – 999s (adjustable via software/ optional) Temperature resolution: 0,15 K (at object temperature >20°C and time constant >0,2s) System accuracy: ±1 % or ±1°C (whichever is greater) Repeatability: ±0,5 % or ±0,5°C (whichever is greater) Temperature coefficient: ±0,05 K/K or ±0,05 %/K Ambient temperature: -20-120 °C (sensor); -20-80 °C (controller) Storage temperature: -40°C - 85°C Power supply: 5-30 VDC Outputs: analogue: 0-5 V or 0-10 V (consumption: 9mA) Inputs: programmable functional input for external emissivity setting (0-5 VDC), Hold function, ambient temperature compensation (via USB programming interface/ optional) Emissivity: 0,100 - 1,100 adjustable via software/optional Transmissivity: 0,100 - 1,100 adjustable via software/optional Signal processing (parameter adjustable via software): peak hold, valley hold, average; extended hold function with threshold and hysteresis LED-functions: alarm indication, automatic aiming support, self diagnostic, temperature indication (via. temp. code) Environmental rating: IP65 for sensor head Scope of supply: Sensor incl. mounting nut, 6 m sensor cable, controller integrated after 3 m in connection cable, manual |
Please Contact Us to Order to offer competitive prices and delivery time for Micro-Epsilon (Eltrotec) - CSmi-SF15-C6/3 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
