BRAND | Demag |
Product | DCM-Pro 1-125 1/1 H4.3 V8/2 380-415/50 |
Internal code | 4860229 |
Technical specification | Supply network Line voltage 400 V Line frequency 50 Hz Three-phase power supply Chain hoist technical data Load capacity 125 kg FEM/ISO group 4m/M7 Hook path 4.3 m Control cable length 4.3 m Weight approx. 26 kg (total net) Shearing 1/1 Lifting speed approx. 8/2 m/min Control voltage 24V AC Hoist voltage 380-415 V/ 50 Hz ZNK 71 A 8/2 lift motor Switch-on time 40/20% Rated power 0.18/0.05 kW Protection class IP 55 Insulation class F Ambient temperature -20°C to +45°C C size 764 mm Surface protection and coloring Lifting unit colour RAL 5009 azure blue High-quality powder coating on the aluminum components of the chain hoist provides excellent corrosion protection. chain storage Standard chain storage designed for 4.3 m hook travel control unit Spiral cable with manulift handle Control switch: DSM 5 with quick-change coupling Control line: 4.3 m spiral cable Other selected options: - with load hook |
Please Contact Us to Order to offer competitive prices and delivery time for Demag - DCM-Pro 1-125 1/1 H4.3 V8/2 380-415/50 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
