BRAND | Mollet |
Product | DF21A1C1F1AS2 |
Description | Rotary vane level gauge |
Internal code | 4442732 |
Custom code | 90318020 |
Technical specification | DF21 limit switch for bulk materials Full, empty and demand detectors for any installation position > >> wide range of application << < A1 aluminum compact enclosure, RAL 7001, protection class IP66 Ambient temperature at control head Ta -20°C... 70°C C1 operating voltage 220... 240 V AC (50... 60 Hz) Signal contact 1 mA 4 V... 2 A 240 V~, floating changeover contact gold-plated contacts (multi-voltage and multi-current switches) H0 function LEDs, yellow=on/blue=full/green=empty E0 bulk material temperature -25 °C... 80 °C P0 suitable for pressure in the container -0.5 bar... 5 bar F1A process connection flange F70 aluminum Dimensions Ø70, Ø110, LK90, 4xØ9 R0 Standard NBR Shaft Seal, Black S2 sleeve-wing S, oblique, 130x30 mm length >LF< = 118 mm, measured along shaft = 52 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Mollet - DF21A1C1F1AS2 Rotary vane level gauge number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
