BRAND	Mollet
Product	DF22A1C6F2AT2LP100U5
Description	Rotary vane level indicator
Internal code	4501542
Custom code	9031 80 20
Technical specification	DF22 limit switch for bulk materials Full, empty and demand detectors for any installation position > >> with extended process connector << < A1 aluminium compact enclosure, RAL 7001, protection class IP66 Ambient temperature at the control head Ta -20°C... 70°C C6 operating voltage 12 V DC Signal contact 1 mA 4 V... 2 A 240 V~, floating changeover contact gold-plated contacts (multi-voltage and multi-current switches) H0 Functional LEDs, yellow=on/ blue=full/ green=empty E0 bulk material temperature -25 °C... 80 °C P0 suitable for pressure in the tank -0.5 bar... 5 bar F2A process connection flange F100 made of aluminum Dimensions 150x150, Lk170, 4xØ18 R0 standard shaft seal made of NBR, black T2 measuring blade T100, 98 x 100 mm length >LF< = 102 mm LP100 process connection length >LP < = 100 mm Cantilever length = 105 mm+>LF < U5 speed of the measuring vane = 5 rpm

Please Contact Us to Order to offer competitive prices and delivery time for Mollet - DF22A1C6F2AT2LP100U5 Rotary vane level indicator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
