DKG-152 - DATAKOM United Kingdom Sales

BRAND	DATAKOM
Product	DKG-152
Description	REMOTE BOOT DRIVE
Internal code	537301
Weight	1
Technical specification	Alternator voltage: 15 to 300 V-AC Alternator frequency: 50 or 60 Hz nominal. Overspeed: nominal frequency + 14% (+24% overdrive) Underspeed: 25 Hz DC supply range: 8 to 33 V DC. Current consumption: 80mA max. (Open outputs). Load fault threshold: 6 V-DC. Load excitation current: through an 82 ohm resistor connected to the FUEL outlet. Preheating delay: 10 sec. Wait before starting: 0.75 sec. Start time: 6 sec. Wait between starts: 10 sec. Number of start cycles: 3 Protection standby timer: 12 sec. Cooling time: 2 minutes. Stop timer: 30 sec. Operating temperature: -20 C (-4 F) to 70 C (158 F). Storage temperature: -30 C (-22 F) to 80 C (176 F). Maximum humidity: 95% without condensation. Dimensions: 72 x 72 x 38 mm (W x H x D) Dimensions of the panel cut: 68 x 68 mm Weight: 140 g (approx.) Installation: Front panel mount. Retention steel spring provided.

Please Contact Us to Order to offer competitive prices and delivery time for DATAKOM - DKG-152 REMOTE BOOT DRIVE number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
