MI-DM0113 DM1133-C++13E0E4WJK-507mm - Interroll United Kingdom Sales

BRAND	Interroll
Product	MI-DM0113 DM1133-C++13E0E4WJK-507mm
Internal code	4840494
Technical specification	Product name DM 0113 Asynchronous 3-phase Certification cRuUS UL Certified Protection grade IP 69K Tube length (SL) 500.0 mm drum width (FW) 507.0 mm Installation length (EL/LW/BF) 520.0 mm Overall axle length (AGL) 570.0 mm Power 370 W Winding number of pins Torque [Nm] 48.0 band tensile force 800 N Gear ratio (i) 42.00 Gear Material name Cast iron: GGG-40 Speed at frequency 1 0.42 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.82 A rated current, low voltage 1.42 A Speed at frequency 2 0.50 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Tube diameter (A) 120.0 mm Tube diameter (B) 118.0 mm ZYL_STD BAL_ZYL_STD tube shape BAL_ZYL Tube option type smooth rubber coating Coating material NBR rubber coating hardness 70 Shore A Coating color white coating process hot vulcanized Cover A version standard cover B version standard Cover A Material stainless steel: 1.4301/304 Cover B Material stainless steel: 1.4301/304 Shaft A version standard Ø25mm shaft B version standard Ø25mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A lock area (F) 20.0 mm Wave B lock area (F) 20.0 mm Shaft A lock surface length (C) 25.0 mm Shaft B lock surface length (C) 25.0 mm Oil type synthetic food oil Electrical connection straight screw connection Elek. Connection material brass CuZn39Pb3/MS58 Power cable length 10.0 m Power cable type shielded; not halogen-free

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0113 DM1133-C++13E0E4WJK-507mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
