| BRAND | Interroll |
| Product | DM 0113 (MI-DM0113 DM1133-A++13B0HRLEH-607mm) |
| Internal code | 4177743 |
| Technical specification | Product Name DM 0113 Asynchronous 3-Phase Degree of protection IP 69K SL Tube length 600.0 mm end face width between lids 607.0 mm EL/LW/BF installation length 620.0 mm AGL axle total length 670.0 mm Power 300 W winding 4 Torque [Nm] 85.1 belt tensile force 1.505 N Gear Ratio 45.00 Transmission Type Cast Iron: GGG-40 Speed at frequency 1 0.18 m/s Frequency 1 50 Hz external connection diagram M31 high voltage 400 V Rated current, high voltage 0.75 A Speed at frequency 2 0.22 m/s Frequency 2 60 Hz high voltage 2 460 V Stainless steel pipe material: 1.4301/304 Tube diameter A 113.0 mm Tube diameter B 113.0 mm Pipe Shape Special Cylindrical Cover A Standard Cover B Standard Standard Lid A Material Stainless Steel: 1.4305/303 Lid B Stainless Steel Material: 1.4305/303 Shaft A Type Standard Ø25mm Shaft B Standard Ø25mm Shaft A Material Stainless Steel: 1.4305/303 Shaft B Material Stainless Steel: 1.4305/303 Wave A wrench width 20.0 mm Shaft B spanner width 20.0 mm Wave A key area length 25.0 mm shaft B spanner length 25.0 mm Oil type synthetic food oil Electrical connection Nipple Elek Connection material TPU Power cable length: 3.0 m, power cable type, shielded; not halogen free |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - DM 0113 (MI-DM0113 DM1133-A++13B0HRLEH-607mm) number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
MI-DMI Drum motor
MI-DMI Drum motor
138i-1500mm Product name 138i Degree of protection IP 66 SL tube length 1500.0 mm 1513.0 mm Stirnflächenweitezw.Deckeln EL / LW / BF installation length 1530.0 mm AGL axis total length 1580.0 mm
DOUBLE WHEEL
Dia. 48 mm bore 8.2 mm
3.5XQ.HF9.N91 DİMENSİONS FOR 2 STEEL SPROCKETS 1/2 Z:14
CONVEYOR 90 ° BACK BAND ROLL
Print: 50 x 1.5 Z11 EL: 650
tapered fixed drive conveyor roller series
Heavy-Duty Conveyor Roller Conveyor Rolle
Steel Ball Transfer Unit
MI-DL0113 DL1133-AAA0AD0ABJSC-295mm
Trommelmotor 113S
MC-MOTOR
BT100; 37: 1; SI; M12; PIPE; SI; 50; x 1.5; BEAD: 2; d 38.4; SB; IG M8; ReDesign
CONTROL CARD INTERROLL 04770600
BU 40 L=1976MM-ROLLCHEN PP 2REIHIG 8MM
Role Type rolls PP 2 row 8mm Total length 1976.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Distance length 1924.0 mm Number of rolls 38
road roller with the necessary mounting dimensions.
BU40 L=520MM ROLLCHEN PP 2REIHIG 8MM
Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type rolls PP 2 row 8mm Overall length 520.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Displacement Length 468.0 mm Number of rolls 10
BU40 L=572MM-ROLLCHEN PP 2REIHIG 8MM
Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type rolls PP 2 row 8mm Overall length 572.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Displacement Length 520.0 mm Number of rolls 11
drum motor
Product name 113S UL approval ULZertifiziert Degree of protection IP 66 SL tube length 490.0 mm 512.0 mm Stirnflächenweitezw.Deckeln EL / LW / BF Installation length 518.0 mm AGL axis total length 558.0 mm Power 180 W winding poles 4 Torque [Nm] 23.8 tensile force 421 N Gear ratio 26.84 GeschwindigkeitbeiFrequenz 1 0.367 m / s Frequency 1 Hz winding 60 phase number 3 high voltage 480 V low voltage 0 V GeschwindigkeitbeiFrequenz 2 0.306 m / s 2 frequency 50 Hz 2 high voltage 440 V low voltage V 2 0 maximum outer diameter 113.3 mm Tube shape sonderballig / pyramidal Steel pipe material: St37-2 / AISI1015
MI-DMI AC138I-LCD0AA0E6LGA-600m
drum motor
