Typ EXN - Orbinox United Kingdom Sales

BRAND	Orbinox
Product	Typ EXN
Description	knife gate
Internal code	4449487
Custom code	84818061
Technical specification	flangers in short installation length, sealing on one side, for installation between flanges according to EN 1092-2 PN 10 Stainless steel mounting bracket, one side with threaded holes M 18 x 1.0 provided for mounting proximity initiators nominal diameter: DN 125 Case: stainless steel CF8M (1.4408) Knife: stainless steel AISI 316 (1.4401) Piston rod: stainless steel AISI 430 (1.4016) mounting bracket: stainless steel AISI 304 (1.4301) stuffing box goggles: stainless steel CF8M (1.4408) Packing: PTFE impregnated synthetic fiber (type ST) with EPDM O-ring Sealing ring: EPDM Seal ring: Type A (standard), stainless steel AISI 316 (1.4401) Contact protection: solid stainless steel sheet Actuation: double-acting pneumatic actuator made of aluminum, hard anodized control pressure: 5 — 7 bar permissible differential pressure in flow direction: DN 50 to 250 = 10 bar, DN 300 to DN 400 = 6 bar DN 450 = 5 bar, DN 500 to DN 600 = 4 bar

Please Contact Us to Order to offer competitive prices and delivery time for Orbinox - Typ EXN knife gate number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
