DRC26-24SB - Deutsch (TE Connectivity) United Kingdom Sales

BRAND	Deutsch (TE Connectivity)
Product	DRC26-24SB
Description	Housing for female terminals
Internal code	537165
Weight	1
Technical specification	Product Type Features Connector Shape: Rectangular Connector and housing type: Female Terminal Housing Connector system: Wire-to-cable Sealable: Yes Hybrid connector: No Main locking function: Contact retainer The connector and contact end in: Wire cable Configuration functions Number of Positions: 24 Number of rows: 4 Electrical characteristics Operating Voltage (VAC): 250 Operating Voltage (VDC): 250 Nominal voltage architecture (V): 24, 48 Characteristics of the body Cable exit angle: 180° Main color of the product: Black Connector and key code: B Contact functions Contact Type: Plug Contact size: size 20 Coupling pin diameter: 1.02 mm [0.04 inches] Contact current rating (max.) (A): 7.5 Mechanical accessory Mating alignment: With Coupling Alignment Type: Keyed Strain relief: With Connector mount type: Cable mount (free hanging) Terminal position guarantee: No Characteristics of the house Housing material: PA GF Center Line (Step): 4.42 mm [0.174 inches] Dimensions Accepts wire insulation diameter range: 1.02 — 2.41 mm [0.04 — 0.095 inches] Row-to-row spacing: 4.42 mm [0.174 inches] Product Length: 27.94 mm [1.1 inches] Product Width: 50.9 mm [2.004 inches] Connector height: 36.45 mm [1.435 inches] Terms of Use Operating temperature (max): 125°C [257°F] Operating temperature range: -55 — 125 °C [-67 — 257 °F] Operation/Application Circuit Application: Signal Industry Standards UL flammability rating: 20 mm flame test according to the UL-94 standard Agency/Standard: SAE J2030 Degree of protection: Not tested Packaging features Packing method: Box Packing quantity: 125 Another Ability to secure the position of the connector: No useful: Yes
