DRC26-40SB - Deutsch (TE Connectivity) United Kingdom Sales

BRAND	Deutsch (TE Connectivity)
Product	DRC26-40SB
Description	Housing for female terminals
Internal code	537166
Weight	1
Technical specification	Product Type Features Connector Shape: Rectangular Connector and housing type: Housing for female terminals Connector system: Wire-to-cable Sealable: Yes Hybrid Connector: No Main locking function: contact retainer The connector and contact end in: Wire and cable Configuration functions Number of positions: 40 Number of rows: 4 Electrical characteristics Operating Voltage (VAC): 250 Operating Voltage (V DC): 250 Nominal voltage architecture (V): 24, 48 Characteristics of the body Cable exit angle: 180° Main color of the product: Black Connector and key code: B Contact functions Contact Type: Socket Contact Size: Size 20 Coupling pin diameter: 1.02 mm [.04 in] Contact current rating (max.) (A): 7.5 Mechanical accessory Coupling Alignment: With Coupling alignment type: with wrench Strain relief: add by accessory Connector mounting type: Wired mount (hanging) Terminal position guarantee: No Characteristics of the house Housing material: PA GF Center Line (Step): 4.42 mm [.174 in] Dimensions Accepts the cable insulation diameter range: 1.02 — 2.41 mm [.04 — .095 in] Row-to-row spacing: 4.42 mm [.174 in] Product Length: 27.94 mm [1.1 in] Product Width: 68.58 mm [2.7 in] Connector height: 32.64 mm [1.285 in] Terms of Use Operating temperature (max): 125 °C [257 °F] Operating temperature range: -55 — 125 °C [-67 — 257 °F] Operation/Application Circuit Application: Signal Industry Standards UL flammability rating: 20 mm flame test according to the UL-94 standard Agency/Standard: SAE J2030 Degree of protection: Not tested Packaging features Packing method: Box Packing quantity: 125 Another Ability to secure the position of the connector: No Repairable: Yes

Please Contact Us to Order to offer competitive prices and delivery time for Deutsch (TE Connectivity) - DRC26-40SB Housing for female terminals number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
