BRAND | Emotron |
Product | FDU48-146 (FDU48-146 54DE---A-NNNNAN--A-B) |
Description | FREQUENCY INVERTERS |
Internal code | 4320079 |
Custom code | 85044088 |
Technical specification | max. motor power (NORMAL): 75 kW Rated output current: 146 A max. motor power (HEAVY): 55 kW Rated output current: 117 A current limit ICL: 175 A Mains voltage: 380-480V (+10%/-15%) Power frequency: 45/65 Hz Output voltage: 0 - mains voltage Output frequency: 0 - 400 Hz Dimensions [HxWxD]: 950x285x314 mm Weight: 60 kg Configuration: FDU48-146 54EN—A-NNNNAN—A-B IP54 degree of protection PPU option D: PPU 4-line EMC Filter E: EMC 2. Environment Download owner's manual: www.emotron.de version 2.1 Stat. -No.: 85044088 |
Please Contact Us to Order to offer competitive prices and delivery time for Emotron - FDU48-146 (FDU48-146 54DE---A-NNNNAN--A-B) FREQUENCY INVERTERS number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
