BRAND | Faggiolati |
Product | G409T1M1-P90AA0 |
Description | pump |
Internal code | 4467601 |
Technical specification | Submersible pump of heavy and hard construction, dry motor type with interposition of the oil chamber between the hydraulic part and the motor side. Impeller type Single channel Free passage (mm) 90 Discharge diameter (mm) DN 100 Suction (mm) DN 100 Cooling By surrounding fluid Motor type M409T-3,2-400/50NN-IE3 - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 3,2 Rated current (A) 6,2 Starting type Direct Supply 3ph 400V-50Hz Nominal speed (rpm) 1392 Winding insulation Class H Duty service S1 Continuous Electric cable N-Neoprene submersible, length 10 m Shaft seal Double Mechanical Liquid max. temperature (°C) < 40 Surface painting Epoxy painting MATERIALS Diffuser Cast Iron EN-GJL-250 Shaft DUPLEX ASTM A890 gr. 4A UNS 31803 SAF 2205 Impeller Cast Iron EN-GJL-250+Ni Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 O-Rings Nitrile Ball bearings Ball bearings life lubricated |
Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G409T1M1-P90AA0 pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
P1=0,5KW 400V-50Hz
(Complete S.S. Aisi 316L- ATEX (Ex d.IIB 4T))
(Complete S.S. Aisi 316L)
Pump
pump
Motor centrifugal pump, vertical
Submersible pump with vortex impeller, 5.2 kW, 400Vß50 Hy, DN 100
Instead produced GV19B1T
Submersible Pump,H= 30 – 5 mt.;Q= 18 – 120 m3/h.;Р= 8,2 kW.;AISI 316;PAPDN100NP04
Impeller type Two Blades Propeller
Cantilever mounting system
thruster
PUMP
Mechanical seal
Mechanical seal
pump
Kit
O-RING
Pump
Auto-coupling System
MECHANICAL SEAL FG 25 CARB.SIL.
MECHANICAL SEAL FA 25 2-B-X
IMPELLER
Pump
