GR32 SMT 16B 55L AC24/B5 S2 RF3 - Settima United Kingdom Sales

BRAND	Settima
Product	GR32 SMT 16B 55L AC24/B5 S2 RF3
Description	screw pump
Internal code	4833094
Custom code	84136070
Technical specification	Q/P (1450 rpm; 46mm²/s; 15 bar) =26.41l/min/1.01kW, NPSH=1.94mWS Q/P (1450 rpm; 257.6mm²/s; 15 bar) =27.09l/min/1.21kW, NPSH=2.44mWS Pump weight: 4.4 kg Country of origin: Italy, customs tariff number: 84136070 GR32 = frame size SMT 16B = pressure level 40 bar 55L = nominal flow AC24/B5 = Direct attachment to electric motor model /B5 (ø200), the required spring (DIN 6885 8x7x28 form A) is included aluminum housing S2 = option for high viscosities (250-500 cSt), poor efficiency RF3 = internal fixed pressure relief valve (15 bar) SAE pressure connection 1 3000psi Standard suction housing with SAE connection 11/4 3000psi NBR sealing material

Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR32 SMT 16B 55L AC24/B5 S2 RF3 screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
