BRAND | Stober |
Product | K302AF0280MQ20 |
Description | Bevel gear with motor adapter |
Internal code | 4864351 |
Custom code | 84834023 |
Technical specification | Replaces serial number: 2029297 MV0000017118 Translation 27.883 Math exact translation 3569/128 Rated torque 350.0 Nm Max.zul. Acceleration torque 385.0 Nm Max. input speed Duration 3500 1/min Motor speed 1500 rpm Max. input speed 5000 rpm cycle Play 10,0 arcmin Load characteristic 1.0 Shaft design Hollow shaft with spring groove Shaft size Ø35 *90178 Position shaft/pinion insert side 4 Round flange housing design Output flange Ø200 c2=38 *90023 Mounting side flange flange page 4 EL3 installation position Output shaft seal double page 3 GS plug coupling design Motor shaft diameter GS24 shaft 24 without passspring * Maximum motor wavelength min. 26 mm - max. 50 One-piece clutch housing design Motor connection □142 95/115 M8 c=98 *91767 Mobilgear 600 XP 220 lubrication* CLP ISO VG 220 K varnish/ 1-coat lacquering Colour RAL 7001 silver grey Painting options Page 4 not painted Documentation language German Documentation language English |
Please Contact Us to Order to offer competitive prices and delivery time for Stober - K302AF0280MQ20 Bevel gear with motor adapter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
