2150000837 - HIMMEL United Kingdom Sales

BRAND	HIMMEL
Product	2150000837
Description	flat motor
Internal code	4707783
Custom code	85015220
Technical specification	K62.01-L/2-G4K M20-RH Like P-528931/1 Dimension sheet: 1NJ100000000093 K model series/design series: K62 Type/type: K62.01-L/2-G4K K size sheet/dimension sheet: 1NJ100000000093 Color/colour: RAL 5015 Sky blue 2K/Sky blue 2K-PUR Design/mounting position: B3 K-mounting sides/mounting sides: one-sided foot processing Protection class: IP54 K rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40 Output variant: flange disc/flange plate W. diameter/shaft diameter [mm]: 30 W. Length/shaft length [mm]: 58 (center foot hole to start tool/center foot Hole to the beginning of tool) Shaft thread: M20-R.H. K flange discs Ø/ external diameter flange [mm]: 90 K tool width/tool width [mm]: 0 - 3 Storage AS/Bearing-AS (DE): Simple bearing Storage BS/Bearing-BS (NDE): Simple bearing K-elect.connection type/elec. connection mode: terminal box/terminal box KK material/Terminal box material: plastic/plastic KK location/Terminal box position: 1B KK screw connection/gland: (2x) -M20x1.5 Electrical version/Electrical design: CE Number of phases: 3~ Number of poles/Poles: 2 Rated power/ Nominal power [kW]: 2.0 Nominal motor speed/Nominal motor speed [1/rpm]: 2820 Nominal frequency/ Nominal frequency [Hz]: 50 Nominal voltage/Nominal voltage [V]: 230/400 Current/Nominal current In [A]: 8.2/4.75 cosPHI/cosPHI: 0.82 Circuit/Wiring: S100 (D/Y) Operating mode/Duty type: S 6-75% Supply type/power supply: Network operation/mains operation Winding protection/Motor protector: PTC 160°C Insulation class/Insulation class: F Motor circuit diagram/Motor connection diagram: A5100003 Built-in circuit diagram 1/Con. diagram compon. 1: A01TP100 Brake type/ Brake type: G4K [3Nm] Brake control system/brake supply voltage [V]: 206-255 Wiring/connection: on clipboard/on terminal block Brake 1 circuit diagram/Connection diagram brake 1: A01BA103

Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - 2150000837 flat motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
