BRAND | Igema |
Product | LG40-CS 13038 |
Description | Reflectance Indicator |
Internal code | 4178244 |
Custom code | 90261089 |
Technical specification | Data sheet: D-02-D-36416-00 Size: 7 Left-model PS = 32 bar, TS = 239 °C PT = 48 bar Center distance A = 350 mm Foam length E = 260 mm Dimensions H = 45 mm, J = 45 mm NW Brand: No Shut-off valve A120-CS with manual lever with ball self-locking, with quick release Data sheet: D-09-D-16354-1 Process connection: flange, Nominal diameter: PN40 DN20 (DIN EN 1092-1-B) Drain valve: AV250 with Ø 12 mm tube connection output Data sheet: D-09-D-34162-0 Standard: DIN Operating Instruction: D-02-B-31946-0 |
Please Contact Us to Order to offer competitive prices and delivery time for Igema - LG40-CS 13038 Reflectance Indicator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
