LI500P0-Q25LM0-ESG25X3-H1181 - Turck United Kingdom Sales

BRAND	Turck
Product	LI500P0-Q25LM0-ESG25X3-H1181
Description	Inductive Linear Position Sensor
Internal code	766075
Weight	1
Technical specification	ID 1590013 Measuring principle Inductive General data Measuring range 500 mm Resolution 0.001 mm Nominal distance 1.5 mm Blind zone a 29 mm Blind zone b 29 mm Reproducibility ≤ 18 µm Linearity deviation ≤ 0.05 % f.s. Temperature drift ≤ ± 0.0001 % / K Hysteresis not applied Electrical data Operating voltage 15…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes Wire breakage/Reverse polarity protection yes / yes (voltage supply) Communication protocol SSi Output function 8-pin, 25 Bit, Gray coded Process data area Bit 0 … Bit 19 Diagnostic bits Bit 21: Positioning element left the measuring range and is outside the detectable area. Bit 22: Positioning element is in the measuring range, lower signal quality (e.g. distance too large)

Please Contact Us to Order to offer competitive prices and delivery time for Turck - LI500P0-Q25LM0-ESG25X3-H1181 Inductive Linear Position Sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
