LS2TR30-150Q8 - Turck United Kingdom Sales

BRAND	Turck
Product	LS2TR30-150Q8
Description	Light Screen for Machine Safety Applications – Receiver
Internal code	766587
Weight	1
Technical specification	Type LS2TR30-150Q8 ID 3073534 Optical data Function Light screen Optical resolution 30 mm Range 200…15000 mm Scan field 150 mm Number of beams 8 With muting function no Scan Code None Electrical data Operating voltage 20…28 VDC Residual ripple < 15 % Uss DC rated operational current ≤ 90 mA No-load current ≤ 90 mA Max. current safe output 500 mA Output function 2 x NC (normally closed), 2 × PNP Current output 500 mA Number of safe semiconductor outputs 2 Response time typical < 11 ms With restart interlock no Blanking function no Mechanical data Design Rectangular, EZ-Screen Dimensions 31.8 x 25.2 x 215 mm Housing material Metal, AL, Yellow polyester Lens plastic, Acrylic Cascadable No Electrical connection Connector, M12 × 1 Number of cores 8 Ambient temperature 0…+55 °C Protection class IP65 Power-on indication LED, Green Switching state LED, Red Tests/approvals Vibration resistance 10-55 Hz at 0.35 mm Shock test 10 g at 16 ms (6000 cycles) Approvals CE, cULus listed

Please Contact Us to Order to offer competitive prices and delivery time for Turck - LS2TR30-150Q8 Light Screen for Machine Safety Applications – Receiver number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
