LX12ESR  - Turck United Kingdom  Sales

BRAND Turck
Product LX12ESR
Description Photoelectric Sensor
Internal code 766052
Weight 1
Technical specification ID:3002682 optical data Function light curtain Operating mode Transmitter Light type IR wavelength 880 nm Optical resolution 5.6 mm Distance 75…200 mm Scanning area 295 mm electrical data Operating voltage 10…30 VDC Leakage fluctuation < 10% Uss No-load current ≤ 100 mA Short circuit protection yes Reverse polarity protection yes Typical response time < 3.2 ms Mechanical Data Design Rectangle, LX Dimensions 31.8 x 25.4 x 342mm Housing material Metal, AL, Gray Lens plastic, Acrylic Electrical connection Cables, 2 m, PVC number of cores 5 Core cross section 0.5 mm2 Ambient temperature -20…+70 °C Optical data Function light curtain Operating mode Transmitter Light type IR wavelength 880 nm Optical resolution 5.6 mm Distance 75…200 mm Scanning area 295 mm electrical data Operating voltage 10…30 VDC Leakage fluctuation < 10% Uss No-load current ≤ 100 mA Short circuit protection yes Reverse polarity protection yes Typical response time < 3.2 ms Mechanical Data Design Rectangle, LX Dimensions 31.8 x 25.4 x 342mm Housing material Metal, AL, Gray Lens plastic, Acrylic Electrical connection Cables, 2 m, PVC number of cores 5 Core cross section 0.5 mm2 Ambient temperature -20…+70 °C

Please Contact Us to Order to offer competitive prices and delivery time for Turck - LX12ESR Photoelectric Sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
