| BRAND | Ascon |
| Product | M5-3102-1200 |
| Description | regulator |
| Internal code | 4730622 |
| Technical specification | M5-3102-1X00 series controller X=2: User manual in German A no.: G no.: Front: 48 x 48 mm Supply voltage: 100... 240 V, 50/60 Hz Logic inputs: 2 Additional input: ext. setpoint input (0-10 V; 1-5 V; 0-5 V; 0/4-20mA) OP1 output: relay (2A/250V closer) OP2 output: relay (2A/250V closer) OP3 output: relay (2A/250V closer) Serial port: without Interface protocol: none Actual value output OP4: without Front color: dark gray Target value program, up to 16 segments They can be freely configured as follows: Input: PT100; thermocouple type J, L, T, K, S, R, T; 0... 50 mV DC 0 (1)... 5 V DC; 0... 10 V DC, 0 (4)... 20 mA Control: ON/OFF, PID, heating or cooling, Heating/cooling, 3 point increments Options: ext. setpoint, current transformer input, continuous control output or serial port Target value/ special functions: Setpoint program, up to 16 segments |
Please Contact Us to Order to offer competitive prices and delivery time for Ascon - M5-3102-1200 regulator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
