| BRAND | Wenglor |
| Product | MLWL131 |
| Description | 2D/3D Profile Sensor |
| Internal code | 4075826 |
| Weight | 0.623 |
| Custom code | 90318020 |
| Technical specification | Optical Data Working range Z 70 ... 130 mm Measuring range Z 60 mm Measuring range X 30 ... 52 mm Linearity Deviation 15 µm Resolution Z 2 ... 4.9 µm Resolution X 17 ... 26 µm Light Source Laser (blue) Wavelength 405 nm Service Life (T = +25 °C) 20,000 h Laser Class (EN 60825-1) 2 Environmental conditions Ambient temperature 0 ... 45 °C Storage temperature -20 ... 70 °C Max. Ambient Light 5,000 Lux EMC DIN EN 61000-6-2; 61000-6-4 Shock resistance per DIN IEC 68-2-27 30 g / 11 ms Vibration resistance per DIN IEC 60068-2-6 6 g (10...55 Hz) Atmospheric humidity 5...95%, non-condensing Electrical Data Supply Voltage 18 ... 30 V DC Current Consumption (Ub = 24 V) 330 mA Measuring Rate 175 ... 6,000 /s Subsampling 350 ... 6,000 /s Inputs/Outputs 4 Switching Output Voltage Drop < 1.5 V Switching Output/Switching Current 100 mA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Interface Ethernet TCP/IP Baud Rate 100/1000 Mbit/s Protection Class III FDA Accession Number 1710273-000 Mechanical Data Housing Material Aluminum, anodised Degree of Protection IP67 Connection M12 × 1; 12-pin Type of Connection Ethernet M12 × 1; 8-pin, X-cod. Optic Cover Glass |
Discover the superior quality and performance of the Wenglor MLWL131 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MLWL131 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MLWL131 :
At RADWARD LTD , we offer the MLWL131 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the MLWL131 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wenglor products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy MLWL131 by Wenglor in United Kingdom?
You can purchase MLWL131 by Wenglor from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the MLWL131?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Wenglor in United Kingdom?
While we are not the official distributor or seller of Wenglor in United Kingdom, we source our products from reliable channels and offer you original Wenglor equipment at competitive prices.
How can I access MLWL131 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for MLWL131 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for MLWL131?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
