MSX-W11-IN-LCD - Dwyer United Kingdom Sales

BRAND	Dwyer
Product	MSX-W11-IN-LCD
Description	Differential Pressure Transmitter
Internal code	4638805
Technical specification	Service Air and non-combustible, compatible gases Wetted Materials Consult factory Accuracy ±0.1% FSO Stability ±1% FSO/year Temperature Limits -4 to 158°F (-20 to 70°C) Pressure Limits Ranges 0 and 1: 3.6 psi max operation, 6 psi burst; Ranges 2 and 3: 6 psi max operation, 6 psi burst Power Requirements 10-36 VDC (2-wire), 17-36 VDC or isolated 21.6-33 VAC (3-wire) Output Signals 4-20 mA (2-wire); 0-10 V, 0-5 V (3-wire) Response Time Instantaneous (default) or 3 s (selectable) Zero and Span Adjustments Digital push-button Loop Resistance Current output: 0-1250 Ω max; Voltage output: min. load resistance 1 kΩ Current Consumption 21 mA max continuous Electrical Connections 4-wire removable European style terminal block for 16 to 26 AWG Electrical Entry ½" NPS thread Display (optional) 4 digit LCD Process Connections ⅛", 3/16", ¼", 5 mm, and 6 mm ID flexible tubing Enclosure Rating NEMA 4X (IP66); UL 2043 (Plenum); UL94 V-0 Mounting Orientation Pressure sensor measurement unaffected by orientation

Please Contact Us to Order to offer competitive prices and delivery time for Dwyer - MSX-W11-IN-LCD Differential Pressure Transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
