MS-111-LCD - Dwyer United Kingdom Sales

BRAND	Dwyer
Product	MS-111-LCD
Description	Pressure Transmitter
Internal code	351493
Weight	1
Technical specification	General Specifications Power Requirements: 10 to 35 VDC (2-wire) 17 to 36 VDC or isolated 21.6 to 33 VAC (3-wire) Service: Air and non-combustible compatible gases Stability: ±1% F.S./year Temperature Limits: 0 to 150°F (-18 to 66°C) Pressure Limits: 1 psi maximum, operation; 10 psi, burst Output Signals: 4 to 20 mA (2-wire); 0 to 5 V, 0 to 10 V (3-wire) Response Time: Field adjustable 0.5 to 15 sec. time constant. Provides a 95% response time of 1.5 to 45 seconds Zero & Span Adjustments: Digital push button Loop Resistance: Current Output: 0-1250 max. Voltage Output: min. load resistance 1 k Current Consumption: 40 mA max Display (optional): 4 digit LCD Electrical Entry: 1/2" NPS Thread. Accessory: Cable Gland for 5 to 10 mm diameter cable Process Connection: 3/16" (5 mm) ID tubing. Maximum OD 9 mm Enclosure Rating: NEMA 4X (IP66) Mounting Orientation: Diaphragm in vertical position

Please Contact Us to Order to offer competitive prices and delivery time for Dwyer - MS-111-LCD Pressure Transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
