| BRAND | Rembe |
| Product | ODV-305x305 |
| Internal code | 4850157 |
| Weight | 7 |
| Custom code | 73269098 |
| Technical specification | Curved, tension-loaded three-piece rupture disc, consisting of upper part, sealing part and vacuum support; particularly suitable for processes with low to medium pressure and vacuum Nominal width: 305 mm Nominal length: 305 mm Relief area: 785 cm² Minimum pressure: 0.093 bar g Maximum pressure: 0.113 bar g Burst pressure: 0.103 bar g Burst temperature: 22 °C Burst tolerance: 10% Vacuum resistance: 1,000 mmWS Upper part: stainless steel Sealing part: PTFE Vacuum support: stainless steel Max. allowable Operating temperature: 230 °C Outer dimensions width: 381 mm Outer dimensions length: 381 mm Certification: ATEX 2014/34/EU Test standard: DIN EN 14797:2006 Testing organization: REMBE EU type examination certificate: FSA 04 ATEX 1538 X |
Discover the superior quality and performance of the Rembe ODV-305x305 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ODV-305x305 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ODV-305x305 :
At RADWARD LTD , we offer the ODV-305x305 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the ODV-305x305 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rembe products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ODV-305x305 by Rembe in United Kingdom?
You can purchase ODV-305x305 by Rembe from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ODV-305x305?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Rembe in United Kingdom?
While we are not the official distributor or seller of Rembe in United Kingdom, we source our products from reliable channels and offer you original Rembe equipment at competitive prices.
How can I access ODV-305x305 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ODV-305x305 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ODV-305x305?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
TRIPLE SECTION BURTING DISC SET.7BA
(C funnel-LEVER®direct 50 VA, VA / HT Type 1, Standardized REMBE®- feed with free inlet using the highest reaching Accuracy. This feed is needed to unify the bulk speed version: Max. Flow rate: 50 m³ / h + 20% in well-flowable products Medium characteristics: dry, good flowability Design: stainless steel 1.5 mm 1.4301 Wear protection: stainless steel sheets 1.4301 Angle of repose: 45 ° Dimensions: see drawing)
(C-50 SS LEVER®direct, Stainless Steel Slide m. cornering Electropolished, capacity: 50 m³ / h at good flowable non-adherent bulk material, installation height: 360 mm without addition funnel adapter or Height with REMBE® feed hopper (z separate supply position B. feed type. 1) mm 620 material to be measured: Particle size mm to 30, Working temperature: -30 ° C to + 70 ° C (-22 ° F to 158 ° F), accuracy: up to ± 0.5% with addition funnel and REMBE® with authorized REMBE® product supply, Execution: Stainless Steel Material: Stainless steel 1.4301 Sealing: silicone rubber Windows: Plexiglass Measuring slide: Stainless steel 1.4301 electro-polished, Approvals: CE - compliant load cell: Construction: stainless steel Housing protection: IP65 Output: 2 mV / V supply Overload: safe to 150% of rated capacity, a maximum of 300%)
Signalgeber BIRD mit 2 m Teflon- Kabel
(EVA-CLD-SS-230, transmitter Stainless steel wall / desk housing, weighing electronics EVA high-end, C-Lever, SS, 230, 20mA Housing: stainless steel as wall / table housing Protection: IP65 Dimensions: 240x180x70 mm Supply: 100 - 240 VAC 50/60 Hz, 15 W max. Display: high-resolution TFT 640 x 480 (8 ") pixels, 256 colors, high brightness 500 cd / m² High contrast 350: 1 Touch Screen 5.7 " Output: 1 analog 0 (4) -20 mA current output 1 floating count contact 2 freely adjustable limit switches Totalizer: 4 pieces encoded resettable Interfaces: RS-232, RS-422, Ethernet, USB, CANBUS Working temperature: -10 ° C to +40 ° C)
Spec : DN 150 Burst pressure Temp 22 C : Min 0.446 barg Max 0.593 barg Temp 80 C : Min 0.430 barg Max 0.570 barg
00014581 Assembly explosion vent 305 x 610
Screw Conveyor
Nachrüstsatz mit 2 m PUR-Anschlusskabel
Knickstab-Umkehr Berstscheibe
rupture disc valve
Materialzeugnis
Standard uni-guard scored reverse bursting disc (capsule insert type)
transmitting
Dreiteil-Berstscheibe, gewölbt
Dreiteil-Berstscheibe, gewölbt
Overpressure rupture disc
Stainless steel
EVA-CLD-SS-230 (224-0000000519)
Evaluation electronics
Knickstab-Umkehr Berstscheibe
Curved, tensile loaded three-part bursting disc
Artikel-Nr.: 164-0000000028 Optional
Material certificate
