Buy Oti Dali 50/220-240/1A4 Lt2 L G2 from Osram in United Kingdom

Q: Where can I buy Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram in United Kingdom?

You can purchase Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

Q: What is the price of the Oti Dali 50/220-240/1A4 Lt2 L G2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Q: Who is the official distributor or seller of Osram in United Kingdom?

While we are not the official distributor or seller of Osram in United Kingdom, we source our products from reliable channels and offer you original Osram equipment at competitive prices.

Q: How can I access Oti Dali 50/220-240/1A4 Lt2 L G2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Oti Dali 50/220-240/1A4 Lt2 L G2 on our website. Visit our resources section or contact us directly for specific documents.

Q: Do you provide technical support for Oti Dali 50/220-240/1A4 Lt2 L G2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND	Osram
Product	Oti Dali 50/220-240/1A4 Lt2 L G2
Description	Led Driver
Internal code	5123218
Weight	0.24
Technical specification	Electrical data: Nominal input voltage: 220…240 V Mains frequency: 0/50/60 Hz Input voltage AC: 198…264 V Input voltage DC: 176…276 V Current set: DALI / LEDset / Programmable Total harmonic distortion: < 15 % Power factor λ: > 0.95 Efficiency in full-load: 90 % Device power loss: 6.0 W Networked standby power: ≤ 0.17 W Protective conductor current: <0.5 mA Inrush current: 20 A Max. ECG no. on circuit breaker 10 A (B) : 13 Max. ECG no. on circuit breaker 16 A (B) : 20 Max. ECG no. on circuit breaker 25 A (B) : - Surge capability (L/N-Ground) : 2 kV Surge capability (L-N) : 1 kV Nominal output voltage: 15…54 V U-OUT (working voltage) : < 60 V Nominal output current: 600…1400 mA Output current LEDset open: 300 mA Output current LEDset shorted: 1400 mA Default output current: 300 mA Output current tolerance: ±3 % Output ripple current (100 Hz) : < 1 % Output PSTLM: ≤1 Output SVM: ≤0.4 Nominal output power: 12…50 W Maximum output power: 50 W Galvanic isolation: SELV Dimensions & weight: Mounting hole spacing, length: 350.0 mm Product weight: 240.00 g Cable cross-section, input side: 0.5…1.5 mm² Cable cross-section, output side: 0.5…1.5 mm² Wire preparation length, input side: 8.0…9.0 mm Wire preparation length, output side: 8.0…9.0 mm Length: 360.0 mm Height: 21.0 mm Width: 30.0 mm Colors & materials: Casing material: Metal Temperatures & operating conditions: Ambient temperature range: -25…+50 °C Maximum temperature at tc test point: 75 °C Max.housing temperature in case of fault: 110 °C Temperature range at storage: -40…+85 °C Permitted rel. humidity during operation: 5…85 % Lifespan: ECG lifetime: 50000 / 100000 h Additional product data: Encapsulated: No Predecessor EAN: 4052899028098 Capabilities: Programming interface: DALI, LEDset Dimmable: Yes Dimming interface: DALI-2 / Touch DIM / Touch DIM Sensor Dimming range: 1…100 % Dimming method: Amplitude Modulation Constant lumen function: Programmable Overheating protection: Automatic reversible Overload protection: Non-reversible Short-circuit protection: Automatic reversible No-load proof: Yes Intended for no-load operation: No Max. cable length to lamp/LED module: 2.0 m Suitable for fixtures with prot. class: I Suitable for emergency lighting: Yes Type of connection, input side: Push terminal Type of connection, output side: Push terminal DALI-2 Diagnostic Data: Yes Number of channels: 1 Control interface: DALI DALI-2 Energy Data: Yes Programming: Programming device: DALI magic Tuner4TRONIC: Yes Tuner4TRONIC Field App: Yes Programmable features Operating Current: Yes Constant Lumen: Yes Lamp Operating Time: Yes Driver Guard: Yes DALI Settings: Yes Emergency Mode: Yes DALI-2 Luminaire Data: Yes Soft Switch Off: Yes Dim to Dark: Yes TouchDIM + Sensor: Yes Corridor Functionality: Yes OEM Key: Yes Certificates & standards: Approval marks – approval: CE / EL / VDE-ENEC / VDE-EMC / EAC / CCC / RCM / BIS Standards: Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 62386 Type of protection: IP20

Discover the superior quality and performance of the Osram Oti Dali 50/220-240/1A4 Lt2 L G2 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The Oti Dali 50/220-240/1A4 Lt2 L G2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of Oti Dali 50/220-240/1A4 Lt2 L G2 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the Oti Dali 50/220-240/1A4 Lt2 L G2 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the Oti Dali 50/220-240/1A4 Lt2 L G2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Osram products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram in United Kingdom?

You can purchase Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the Oti Dali 50/220-240/1A4 Lt2 L G2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Osram in United Kingdom?

While we are not the official distributor or seller of Osram in United Kingdom, we source our products from reliable channels and offer you original Osram equipment at competitive prices.

How can I access Oti Dali 50/220-240/1A4 Lt2 L G2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Oti Dali 50/220-240/1A4 Lt2 L G2 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Oti Dali 50/220-240/1A4 Lt2 L G2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
